Relays
General Purpose Relays
38 series interface relays. DIN rail mount, integral base, LED indication.
SPDT/6A, DPDT/8A
40 series slimline relays. Base & PCB mount.
SPDT/10A, SPDT/16A, DPDT/8A
46 series slimline relays. Lockable test button & LED indication.
SPDT/16A, DPDT/8A, 12V, 24V DC & 12V, 24V, 110V, 230V AC
55 series relays. Flat-pine style, lockable test button, LED indication.
DPDT/10A, 4PDT/7A
56 series relays. Flat-pine style, lockable test button, LED indication.
DPDT/12A, 4PDT/12A
60 series relays. Round-pine style, lockable test button, LED indication.
60.12 8-pin DPDT/10A, 60.13 11-pin 3PDT/10A
Power Relays
62 series power relays. PCB & Faston 250 connection (6.3mm).
16A 250Vac contact rating. DPDT & 3PDT, 12/24V DC & 230Vac
65.31 power relays. Rear flange mount, Faston 250 connections (6.3mm).
SPNO/30A, 24Vac, 24Vdc & 230Vac
66.82 power relays. Flange mount, Faston 250 connections (6.3mm).
DPDT/30A, 12V, 24V AC/DC & 110V, 230V AC
Stepping/Latching & Monostable Relays
20 series stepping./atching relays.
Two 16A contacts, NO & NC options, 12V & 24V DC, 12V, 24V, 110V, 230V AC
22 series monostable relays.
Two 16A contacts, NO & NC options, 12V & 24V DC, 12V, 24V, 110V, 230V AC
26 series surface mount stepping/latching relays.
Two 10A contacts, NO & NC options, 12V, 24V, 110V, 230V AC. Adaptor available for DC use.
Solid State Relays
GN Series Panel mount solid state relays. LED indicator.
Load 24-280Vac 10A to 125A. Inputs 4-32Vdc, 90-280V ac/dc & 18-36V ac/dc
GNR 22.5mm DIN rail mount solid state relays.
Loads 24-280Vac 10A & 48-600Vac 20A. Inputs 4-32Vdc & 180-280V ac/dc
GNR 45mm DIN rail mount solid state relays.
Loads 48-600Vac, 35A & 40A. Inputs 4-32Vdc & 180-280V ac/dc
