Multifunction Electricity Metering
|
 |
Multifunction Panel Meters
From TE Connectivity
|
|
|
|
Integra Ci3 Digital Metering System
- Designed and made in the UK
- DIN 96x96 standard format
- Plug-in output module options
- Isolated pulse outputs
- RS485 MODBUS® comms
- Free TE DataX energy monitoring software available
- True rms measurement
|
|
|
|
Integra 1630 MODBUS® Digital Metering System
Multifunction digital metering with high accuracy 0.2% measurement.
Display and communicate all major electrical parameters including THD.
- MODBUS® TCP comms
- 0.2% accuracy
- True rms measurement
- 10/100Mbps Ethernet
- High contrast LED display
|
|
|
|
Integra 1630 BACnet/IP Digital Metering System
Multifunction digital metering with BACnet/IP protocol support.
Display and communicate all major electrical parameters including THD.
- BACnet/IP protocol ANSI/ASHRAE 135-1995 Annex J
- 0.2% accuracy
- True rms measurement
- 10/100Mbps Ethernet
- High contrast LED display
|
|
|
|
Integra 1630 Multifunction Digital Metering System with
Profibus DP Communications Option
Display and communicate all major electrical parameters including THD.
- ProfibusTM DP protocol
- 0.2% accuracy
- True rms measurement
- High contrast LED display
|
|
 |
Multifunction Panel Meters
Manufactured by ND Metering Solutions
|
|
|
|
Cube 400 Multifunction Panel Meter
- Designed and made in the UK with a 5 year warranty
- DIN 96x96 standard format
- True rms measurement to the 30th harmonic
- Individual harmonics to the 15th
- Isolated pulse outputs
- IP54 protection
- RS485 MODBUS® or TCP/IP Ethernet comms
|
|
|
|
Cube 350 Multifunction Panel Meter
- Designed and made in the UK with a 5 year warranty
- DIN 96x96 standard format
- True rms measurement to the 30th harmonic
- Individual harmonics to the 15th via MODBUS®
- Isolated pulse outputs
- IP54 protection
- RS485 MODBUS® or TCP/IP Ethernet comms.
|
|
 |
Multifunction Panel Meters
Manufactured by Deif
|
|
|
|
Multi-instrument type MIB
- Microprocessor-based measuring instrument
- Single or 3-phase TRMS measurements of voltage and current
- Calculation of all common power and energy parameters
- DIN 96x96 standard format
- Optional isolated pulse outputs
- Optional RS485 MODBUS® comms
|
|
|
|
Multi-instrument type MIC
- Microprocessor-based measuring instrument
- Single or 3-phase TRMS measurements of voltage and current
- Calculation of all common power and energy parameters
- Four-quad energy measurement, energy counting
- DIN 96x96 standard format
- RS485 MODBUS® or TCP/IP Ethernet comms
|
|
|
|
Multi-instrument type MIC-2
- Microprocessor-based measuring instrument
- Modular design for great flexibility
- Optional modules for RS485, TCP/IP Ethernet & IO
- Power quality analysis
- Single or 3-phase TRMS measurements
- Calculation of all common parameters
- Four-quad energy measurement, energy counting
- DIN 96x96 standard format
- RS485 MODBUS® or TCP/IP Ethernet comms.
- Utility software - data logging, remote reading
|
|
|
|
Multifunction DIN Rail Mounted Metering
From TE Connectivity
|
|
|
|
Integra Ri3 Digital Metering System
- Designed and made in the UK
- DIN rail mounted, 72mm 4M wide
- Isolated pulse outputs
- RS485 MODBUS® comms
- True rms measurement
- Free TE DataX energy monitoring software available
|
|
|
Multifunction DIN Rail Mounted Metering
Manufactured by ND Metering Solutions
|
|
|
|
Rail 350 Multifunction Metering
- Designed and made in the UK with a 5 year warranty
- DIN 96x96 standard format
- True rms measurement to the 30th harmonic
- Individual harmonics to the 15th
- Isolated pulse outputs
- RS485 MODBUS® comms
|
|
|
|
Data sheet
